This popular 5.5' x 9' Steel Utility Trailer is suited for an extensive range of applications and is equipped with patented fold-down rails that allow for easy loading via forklift. Karavan's Dove Tail Ramp reduces load angle when loading zero turn mowers. Road performance is excellent via Karavan's SwayControl and QuietTow engineering. Reliability is built in with smart lighting and wheel bearing systems. We finish it with a powder coat finish as attractive as durable.
- INNOVATIVE AND PATENTED FOLD-DOWN RAILS Allows easy side loading, longer and wider loads; removable
- 17-STEP POWDER COAT FINISH Long-lasting protection vs. spray technique used on most trailers
- QUIETTOW COMPONENTRY Less noise via lockable tensioner latches, nylon bushing springs
- HEAVY DUTY REMOVABLE RAMP Expanded metal to support the loading of heavy equipment
- WOOD PLANK FLOOR Treated 2 x 6 in. deck boards protect against decay and termites
- COATED SELF-COILING SAFETY CABLES Cables coil out of the way when not in use
- HIGH RELIABILITY SHORTFREE LIGHTING SYSTEM Fully grounded and all plug (no Scotchloks); wiring is concealed
- SURE-LUBE WHEEL BEARING GREASE SYSTEM Allows quick and clean greasing for easy maintenance
- TONGUE JACK INCLUDED Foot plate sold separately
- INTEGRATED DOVETAIL Reduces ramp angle for easy loading
Specifications
| Specification | Description |
|---|---|
| Brand | Karavan |
| Country of Origin | Made in USA |
| Approximate Trailer Size (W x L) ft. | 5.5 x 9 |
| Axle Size | 3,750 lb. |
| Bed Length | 9 ft. |
| Bed Width | 5.5 ft. |
| Coupler Size | 2 in. |
| Coupler Type | A-frame |
| Empty Weight | 825 lb. |
| Features | Patented Fold-Down Rails, Powder Coated Paint, Integrated Dovetail, SwayControl Engineering, Coated Self-Coiling Cables, Fully grounded and all plug wiring, Tongue Jack Included, |
| Floor Material | Wood |
| Frame Material | Steel |
| Gate Length | 49 in. |
| Gate Width | 67 in. |
| Gross Vehicle Weight Rating | 2,990 lb. |
| Hitch Type | 1-Ball |
| Number of Axles | 1 |
| Number Of Ramps | 1 |
| Number Of Stalls | 0 |
| Number Of Windows | None |
| Ramp Type | Back |
| Rear Door Style | Ramp |
| Tire Size | ST 18,580R 13D |
| Tongue Length | 49 in. |
| Tongue Type | A-FRAME |
| Trailer Brake Type | None |
| Trailer Features | Removable Ramp, Wood Floor, Jack Included, Powder Coated, Ramp Included |
| Trailer Max Load Capacity lb. | 2165 |
| Warranty | Karavan Trailers, Inc. warrants each new Karavan Trailers trailer to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase or two (2) years from date of manufacture. |
